| Focus System |
Auto, Manual |
| Shutter Speed |
1/50s ~ 1/10000s |
| Minimum Illumination |
0.1Lux |
| Exposure |
Auto, Manual, Iris Priority, Shutter Priority, Brightness priority |
| White Balance |
Auto, Indoor, Outdoor, Keying, Auto Tracking |
| Backlight Compensation |
Support |
| Digital Noise Reduction |
2D&3D Digital noise reduction |
| S/N Ratio |
≥50dB |
| Pan/Tilt |
| Pan Angle |
355° |
| Tilt Angle |
-30°~+90° |
| Pan Speed |
1°~80°/s |
| Tilt Speed |
1°~60°/s |
| Preset Positions |
9 preset positions by IR remote controller, 255 preset positions by joystick controller |
| Preset Accuracy |
0.1°±10% |
| Flip |
Support |
| Image Freeze |
Support |
| POE |
802.3af |
| AI |
| Intelligent tracking |
Support |
| Auto Framing |
Support |
| Gesture Recognition |
Support |
| USB |
| Protocol |
UVC 1.1, UAC1.0 |
| Operating System |
Window7 and above, MacOS, Linux, Android |
| Video Compression |
YUY2, MJPEG |
| Resolution |
MJPEG: 3840*2160, 2560*1440, 1920*1080, 1280*720, 960*540, 800*600, 720*576, 720*480, 640*480, 640*360, 352*288, 320*240
YUY2: 1920*1080, 1280*720, 960*540, 800*600, 720*576, 720*480, 640*480, 640*360, 352*288, 320*240 |
| Frame Rate |
Max.60 |
| UVC Control |
Support |
| LAN |
| Protocol |
TCP/IP, HTTP, RTSP, RTMP, RTMPS, SRT, Onvif, DHCP, VISCA Over IP, Free D, NDI®HX2 (Optional) |
| Video Compression |
H.264, H.265 |
| Code Stream |
Main code stream*1, Sub code stream*1 |
| Main Stream Resolution |
3840*2160, 1920*1080, 1280*720 |
| Sub Stream Resolution |
640*480, 640*360, 352*288, 320*240, 176*144 |
| Bitrate Control |
VBR, CBR |
| Audio |
| Audio Compression |
AAC |
| Audio Bitrate |
48K and 44.1K |
| Interface |
| HDMI Interface |
1 Line, HDMI: Version 2.0 |
| SDI Interface |
1 Line, 3G-SDI |
| USB Interface |
1 Line, USB3.0, Type-B Socket |
| Network Interface |
1 Line, RJ45: 1000M adaptive Ethernet port |
| Audio Interface |
1 Line, Line In, 3.5mm |
| Serial Interface |
1 Line, RS232 IN/OUT: 8-Pin Mini Din, up to 30 meters, VISCA/Pelco-D/Pelco-P Protocol.
1 Line, RS422/485: 9-Core Phoenix Interface, up to 1200 meters, VISCA/Pelco-D/Pelco-P Protocol. |
| Power Interface |
JEITA RC-5320A Type 4 |
| General Specifications |
| Tally Light |
Support |
| Input Voltage |
DC 12V |
| Input Current |
Max.2.0A |
| Power Consumption |
Max.24W |
| Operating Temperature |
0~40℃ |
| Storage Temperature |
-10~60℃ |
| Color |
Black, White (Optional) |
| Dimension |
(W)134*(D)174*(H)191mm |
| Weight |
1.2kg |
| Accessories |
DC 12V power adapter, IR Remote, User manual, USB3.0 Cable, RS-232C Cable, Ceiling bracket, Wall bracket(Optional) |
